BECKMAN COULTER AU 640

---

The Beckman Coulter AU640 Chemistry system, formerly the Olympus AU640 boasts over 90 assays with a maximum throughput of 800 tests per hour. The AU family of systems are well regarded, open reagent, high quality chemistry systems that are considered one of the most popular chemistry systems on the market, in particular in the US laboratory marketplace. Chemistry analyzers measure substances within bodily fluids to establish a pattern of abnormalities. The wide range of tests can be grouped under several categories such as electrolytes, enzymes, blood sugar, metabolites, thyroids, hormones, lipids, therapeutic drug monitoring, and drugs of abuse monitoring. This analysis can be conducted on blood (either whole, serum or plasma), urine, semen or cerebrospinal fluids Chemistry analysis begins with patient sample placed in separate capsules, test tubes, slides or sample cups that are transported on a conveyor with sample racks or in a carousel in a reagent tray. Specimens are sampled and then mixed automatically together with diluents and reagents in a reaction cuvette. The reagents are pulled from a reagent carousel, which is typically refrigerated to keep the reagents shelf life longer. The reactive cuvette is stored and processed in the Reaction carousel. The Reaction carousel holds the mixing station (which mixes samples and reagents) and wash station (which rinses the cuvettes). Dependent on the manufacturer, the cuvette is either made of glass or plastic, but must be optically clear so that light may pass through without any intervention from scratches or blemish. Chemistry analysis is calculated through the absorbance of the specific wavelengths as light is passed through the specimen. All chemistry analyzers possess a photometer (either filter photometer or spectrophotometer) that conducts the measurement of the light absorbance of the specimen, and results are calculated. Filter photometers use glass filters, on a rotating filter wheel, coated with colored material while spectrophotometers use prisms or gratings, to isolate these wavelengths from the scanner beam. In both cases, a lamp (typically halogen) is the light source. Spectrophotometry is a more commonly used method than Filter photometry, which is currently only used in J&J, Roche Cobas and Siemens Dimension systems. Spectraphometry is used in most other systems including Abbott, Beckman and Roche Hitachi systems. The process to attain the results from the absorbance tests are classified either as End Point or Kinetic. End point method incubates the reaction mixture for a predetermined amount of time to reach the end point, or equilibrium of the reaction. Kinetic method, as the reagents and the sample are mixed, the reaction is monitored, the rate of change in absorbance is then determined and related to analyte concentration. As such, Kinetic is a faster method than End Point.

Assay Methodology:   Single-End Point Assay, Dual-End Point Assay, Rate Assay, Fixed Point Assay

Auto Dilution:  Yes

Auto Sample Handling:  No

CLIA Complexity:  Moderate

Configuration:  Floor Model

Depth:  80 cm (31 in)

Direct Sample (STAT): Yes

Height:  125 cm (49 in

)Maintenance Free Electrodes:  Yes

Manufacturer:  Beckman Coulter

Maximum Throughput:  800 tests/hour

Number of Assays:  89

On-Board Refrigeration:  Yes

Optical Source:   Halogen Lamp
Optical System:  Photometric
Patient Sample Capacity:  150

Point Of Care:  No

Power Supply:  110V-220V

Reagent Capacity:48

Reagent Delivery:  Automatic Pipetting

Reagent System:  Open

Reagent Type:  Liquid

Sample Cycle Time:0 (sec)

Sample Input Closed Tube:  No

Sample Input Type:  Sample Tubes Sample Cups
Sample Size Max:  50 μL

Sample Size Min:  1 μL

Sample Types:  CSF, Plasma, Urine, Serum

Series:  AU

Standby Mode:  Yes

Test Method:  Light Absorbancy
Water Consumption:33 (L/hour)

Water OnBoard Supply:  Yes

Water Requirement:  Yes

Weight:530 kg (1166 lb

)Width:185 cm (73 in)
